• A stainless steel Fisher Internal Valve - 3" MNPT x 3" FNPT (C477-24-46) with a red label, featuring bolts and metallic components designed for LPG handling, photographed against a plain background.
1 1

Fisher

MPN: C477-24-46

Fisher Internal Valve - 3" MNPT x 3" FNPT, Stainless Steel, 460 GPM (C477-24-46)

Fisher Internal Valve - 3" MNPT x 3" FNPT, Stainless Steel, 460 GPM (C477-24-46)

FIC477-24-460

$1,754.00 USD
$1,754.00 USD
Sale Currently Sold Out - Back Orders Possible

High-Performance Jet Bleed Internal Valve for Rapid Pressure Equalization

The Fisher C477-24-46 Jet Bleed Internal Valve offers rapid pressure equalization and quick response for efficient LPG and NH3 handling in bobtail, transport, and stationary tank applications.

Key Features and Benefits

  • Compact, one-piece body design: Space-saving and economical solution
  • Stainless steel construction with low-temp seal: Ensures durability and reliability
  • 460 GPM (1,741 LPM) flow rate: Enables fast and efficient fluid transfer
  • Jet bleed technology: Provides rapid pressure equalization and quick valve response
  • Versatile actuation options: Manual, cable control, or air cylinder for operational flexibility
  • NFPA 58 compliant: Meets safety standards for LPG and NH3 service

Technical Specifications

Specification Detail
Connection 3" MNPT x 3" FNPT
Material Stainless Steel
Flow Rate 460 GPM (1,741 LPM)
Seal Type Low Temperature
Actuation Methods Manual, Cable Control, Air Cylinder
Compliance NFPA 58
Applications LPG, Anhydrous Ammonia (NH3)
Installation Types Bobtail, Transport, Stationary Tank, In-Line
